L: Wafer-level reliability testing Model 4200A-SCS Parameter Analyzer

Reference Manual

L-18 4200A-901-01 Rev. C / February 2017

Notes on output variables

test_status:

• 0: No test errors (exit due to measured voltage < factor of the previous value).

• 1: Failed pre-stress test.

• -2: Cumulative charge limit reached.

• -3: Maximum time limit reached.

• -4: Masked Catastrophic Failure.

• -5: Non-Catastrophic Failure.

• -6: Invalid specified t_step.

Invalid Test Result - Result = 1e21.
