Keithley 4200A-SCS Reference Manual

Section
6: Clarius Model 4200A-SCS Parameter Analyzer
Reference Manual
6-52 4200A-901-01 Rev. C / February 2017
Parameter Description
Parameters (on page 6-58)
Select the type of parameters. When using any of the tests supplied by
Keithley Instruments, leave the measurement option set to
Cp-Gp
.
Param1 Column Name (on page 6-
58)
The name that is used for parameter 1 in the Analyze sheet.
Param2 Column Name (on page 6-
58)
The name that is used for parameter 2 in the Analyze sheet.
Report Test Conditions (on page 6-
58)
Select this option to display the DC bias and drive frequency values on the
Analyze sheet.
DCV Column Name (on page 6-59)
Available if you select Report Test Conditions. Determines the name of the
column that contains the DC bias information in the Analyze sheet where
this data is reported. You can change the name of the column by typing a
new value.
Freq Column Name (on page 6-59)
Available if you select Report Test Conditions. Determines the name of the
column that contains the frequency information in the Analyze sheet where
this data is reported. You can change the name of the column by typing a
new value.
Report Status (on page 6-59)
When this option is selected, Clarius records measurement status
information when the test executes. A column of the Analyze spreadsheet
displays this information. Hover over a cell to review the information.
Compensation Open (on page 6-59)
Use the CVU connection compensation value that was generated for open
connection compensation. Refer to Connection compensation (on page 4-
10) for information on generating and using compensation values.
Compensation Short (on page 6-59)
Use the CVU connection compensation value that was generated for short
connection compensation. Refer to Connection compensation (on page
4-
10) for information on generating and using compensation values.
Compensation Load (on page 6-60)
Use the CVU connection compensation value that was generated for load
compensation. Refer to Connection compensation (on page 4-10
) for
information on generating and using compensation values.
Compensation Cable Length (on
page 6-60)
The cable length that was used to generate connection compensation data.
Make sure this cable length is the same as the Cable Length setting in the
Tools > CVU Connection Compensation dialog box. Refer to
Connection
compensation (on page 4-10) for additional information.
AC Source V (on page 6-60)
Selects the terminal to use to source AC drive voltage.
AC Measure I Range (on page 6-60)
The measure range determines the full-scale measurement span that is
applied to the signal.
DC Source V (on page 6-60)
Selects the terminal to use to source DC drive voltage.
DC Offset (on page 6-60)
Allows you offset the voltage by up to ±30 V on one terminal. For example,
this allows you to output voltage from 0 V to 60 V instead of
−
30 V to +30 V.
Capacitance Range Estimator (on
page 6-61)
The Capacitance Range Estimator automatically calculates the maximum
capacitance value based on the parameter settings in the Advanced settings
dialog box.
