Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 6:
Clarius
4200A-901-01 Rev. C / February 2017 6-113
Modify a group
To modify a group:
1. Click the tab for the group. If a tab is not shown, use the left or right sheet buttons to move the
groups until the tab displays (the arrow buttons are to the left of the All tab).
2. You can change the following group-level items (see the example in Add a group (on page
6-
112)):
 Group name.
 Group position.
 Parameter order: Select a parameter row, and then click Move Up or Move Down to change
the position of the parameter in the group box.
 Parameters in the group: To remove a parameter from a group, select the parameter row
and click the Remove button. To remove all parameters from the group, click Remove All.
To add a parameter, click Add and then select and configure the parameter.
Figure 277: UTM UI Editor group position example
