A-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-179
Run an individual test
To abort a test, select Stop. All test and action execution stops immediately.
To run an individual test in the project tree:
1. In the project tree, make sure the check box for the test is selected.
2. Highlight the test.
3. Select Run. The Run icon changes as shown below. The active test is listed to the left of Run.
The Stop icon changes to red.
Figure 340: Run icon while a test is running
When the test completes, a beep sounds and the run arrows around the Run icon are no longer
displayed.
In the following example, only the gummel test runs. Even though the other tests are selected, they
are at the same level as the gummel test in the hierarchy.
Figure 341: Run specific tests
