-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-217
Add or update a title
To add or update the title of the graph:
1. On the graph, right-click and select Title. The title is displayed at the top of the graph and the
Title Properties dialog box is displayed.
Figure 373: Example of graph title and properties
2. Change the appearance of the title as needed. See the table below for descriptions of the
options.
3. Click OK.
4. If needed, drag the title to a new location on the graph.
Option Description
Title
Foreground
Background
Transparent
Select to display the title with a transparent background. Clear to make the
background solid.
Note that selecting Transparent sets the background color selection to light gray.
Display Font
Border Style
Changes the type of outline around the box. Width must be set to a value other
than 0 in order for the border to be displayed.
Border Width
The width of the display border (0 to 20).
Visible
Select to display the title. Clear to hide the title. The settings are maintained
when the title is hidden.
