Appendix A
A-126 MIPS R4000 Microprocessor User's Manual
Format:
SC rt, offset(base)
Description:
The 16-bit offset is sign-extended and added to the contents of general
register base to form a virtual address. The contents of general register rt
are conditionally stored at the memory location specified by the effective
address.
If any other processor or device has modified the physical address since
the time of the previous Load Linked instruction, or if an ERET instruction
occurs between the Load Linked instruction and this store instruction, the
store fails and is inhibited from taking place.
The success or failure of the store operation (as defined above) is indicated
by the contents of general register rt after execution of the instruction. A
successful store sets the contents of general register rt to 1; an unsuccessful
store sets it to 0.
The operation of Store Conditional is undefined when the address is
different from the address used in the last Load Linked.
This instruction is available in User mode; it is not necessary for CP0 to be
enabled.
If either of the two least-significant bits of the effective address is non-zero,
an address error exception takes place.
If this instruction should both fail and take an exception, the exception
takes precedence.
SC
Store Conditional
31 2526 2021 1516 0
SC base rt
offset
655 16
1 1 1 0 0 0
SC
