Appendix A
A-150 MIPS R4000 Microprocessor User's Manual
Format:
SUB rd, rs, rt
Description:
The contents of general register rt are subtracted from the contents of
general register rs to form a result. The result is placed into general
register rd. In 64-bit mode, the operands must be valid sign-extended, 32-
bit values.
The only difference between this instruction and the SUBU instruction is
that SUBU never traps on overflow.
An integer overflow exception takes place if the carries out of bits 30 and
31 differ (2’s complement overflow). The destination register rd is not
modified when an integer overflow exception occurs.
Operation:
Exceptions:
Integer overflow exception
SUB
SUB
Subtract
31 2526 2021 1516
SPECIAL rs rt
655
rd 0 SUB
55 6
11 10 6 5 0
0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0
32 T: GPR[rd] ← GPR[rs] – GPR[rt]
64 T: temp ← GPR[rs] - GPR[rt]
GPR[rd] ← (temp
31
)
32
|| temp
31...0
