MIPS R4000 Microprocessor User's Manual A-155
CPU Instruction Set Details
Format:
SWL rt, offset(base)
Description:
This instruction can be used with the SWR instruction to store the contents
of a register into four consecutive bytes of memory, when the bytes cross
a word boundary. SWL stores the left portion of the register into the
appropriate part of the high-order word of memory; SWR stores the right
portion of the register into the appropriate part of the low-order word.
The SWL instruction adds its sign-extended 16-bit offset to the contents of
general register base to form a virtual address which may specify an
arbitrary byte. It alters only the word in memory which contains that byte.
From one to four bytes will be stored, depending on the starting byte
specified.
Conceptually, it starts at the most-significant byte of the register and
copies it to the specified byte in memory; then it copies bytes from register
to memory until it reaches the low-order byte of the word in memory.
No address exceptions due to alignment are possible.
SWL
Store Word Left
31 2526 2021 1516 0
SWL base rt
offset
655 16
1 0 1 0 1 0
SWL
address 0
address 4
0123
4567
ABCD
register
address 0
address 4
0
4567
ABC
$24
memory
(big-endian)
before
after
SWL $24,1($0)
