Suggested Tools for Moving and Installation
The type of equipment used to move products to the bolt down location
should be determined by location ooring, layout and construction
Tidel recommends lifting/moving duties be performed
by a minimum of (2) persons
Moving Equipment:
Note: Weight rating for moving equipment should meet or exceed TR Series specifications
J Bar
“Sliders” or “Slick Sticks”
4 wheel or triangular dolly
Heavy duty hand truck
Pallet Jack
6-10 round steel bars
6-10 1/2 diameter PVC tubing sections 8-10” in length
Scissor jacks or small oor jacks
6-10 lb short handle sledge hammer with 2 X 4 wood block
1/2” wrench or socket/ratchet
Flooring can be protected by alternately placing cardboard or plywood in the moving
pathway.
Installation Tools:
Anchor setting tool for 1/2 drop-in anchor
Hammer
5-10 lb short handle sledge hammer with a 2x4 wood block
Vacuum (to remove concrete dust from anchor holes)
SAE wrench set
SAE socket/ratchet set
Phillips head screwdriver
Anchor Specications
Tidel recommends using the supplied drop-in anchor kit to secure the unit to concrete floors. This kit
consists of:
6- 1/2” steel drop-in anchors Tidel P/N 501-1078-001
6- 1/2” x 1-1/4” hex head bolts Tidel P/N 501-1051-051
6- 1/2” flat washers Tidel P/N 501-1050-011
Standard concrete (4000 PSI), which can be found in most locations, will provide a suitable base for
securing Tidel equipment to the floor.
When the Tidel equipment is secured to this type of floor, with the above mentioned anchors, bolts and
washers, it will require at least 6,000 pounds of vertical pressure or 8,420 pounds of horizontal pressure,
per anchor, to forcibly remove the anchors from the floor.
NOTE: Although six (6) anchor points are provided in the bottom of the unit, it may not be possible to
install anchor bolts in all points due to obstructions in the foundation, drill drift or other factors.
Anchoring the unit with at least 4 bolts (preferably diagonally opposed), should prove sufficient.
