Combination Lock Battery Replacement
Repeated beeping during opening or a continuous flashing LED indicates a low battery condition.
The battery should be replaced immediately with a 9vdc alkaline battery.
1) Gently pull down on the Battery Cover Handle to remove the Battery Cover.
2) Remove and replace the Battery.
3) Place the Battery Cover so that one end of the cover is inserted into the Combination Lock body
first, then snap the opposite end into place.
X Ensure the lock dial is in the locked position (keypad level and straight).
X Ensure the wires connected to the battery are not protruding from the battery cavity.
Combination Lock Keypad
LED
Battery Cover Handle
