6-3

6

Hardware Support PCB

J8

ORG = +24 VDC

BLU = +12 VDC

WHT = +5.00 ~ 5.10 VDC

RED = +5.00 ~ 5.10 VDC

J13

J18

J10

J19 J4

J7

VDC Test Points

J16 J15

+24

Voltage Present

LEDs

+12

+5
