Tidel TR303 - Coin Handler Door Sensors

6-12
6
Coin Handler Door Sensors
The (2) Coin Handler Vault Door Sensors are wired in series - in order to function/
test properly, both sensor must be blocked simultaneously.
Unblock only 1 sensor to check for a reaction,
Replace the block on the sensor, then remove the block from the second Sensor in
the series to check for a reaction
1) Turn the Cash Handler Vault Door “T” Handle(s) to the locked position.
2) Turn the Combination Lock housing Counter-Clockwise (locked).
a) Insure the housing cannot be rotated Clockwise (unlocked).
b) Insure the Vault Door Handle(s) cannot be turned to the unlocked position.
The displayed Sensor Map should indicate the DOOR Sensor is UNLOCKED
3) Block the DOOR Sensor, located in the top/outside corner of the Coin Handler Vault Door.
The displayed Sensor map should indicate the DOOR Sensor is CLOSED.
4) While continuing to block the DOOR Sensor, activate the Solenoid by selecting the Coin
Handler Vault from the Sensor Map.
a) The Solenoid should activate.
b) The displayed Sensor Map should indicate the DOOR Sensor is UNLOCKED.
c) The Door Handle can be turned to the unlocked position.
5) Return the “T” Handle and Combination Lock to the locked position.
6) Enter the default combination 1-2-3-4-5-6.
a) 2 beeps indicate correct entry.
b) Rotate the Combination Lock housing clockwise (unlocked)
c) Turn the Vault Door “T” Handle(s) to the UNLOCKED position.
Testing Sensors (Diagnostic Test)
