Tidel TR303 - Rear Connections

To Next Page

To Previous Page

15-8

Rear Connections

USB Port = Keyboard/ThumbDrive

RJ-45 = Network Comm (Blue)

C = Rolled Coin Dispenser

USB Cable = Coin Sorter

D = Coin Handler (Door/Hopper control)

USB Port

RJ-45

USB

Note Handler

Incoming VAC Power

Component

Power Supplies VAC

Component Power Supplies

VAC - ON/OFF Switch
