11-6

Cassette Damage Warning

Damage to the Recycle Cassettes can occur if the Cassette Rack is released while the Note Recycler is

extended.

DO NOT RELEASE THE

CASSETTE RACK RELEASE LEVER

WHEN THE NOTE RECYCLER IS EXTENDED

DAMAGE WILL RESULT !!

Note Recycler

Release Lever
