Tidel TR303 - Reject Cassette Placement

To Next Page

To Previous Page

11-39

Lift point

Reject Cassette Placement

1) Lift the Reject Frame slightly

2) Lift the Reject Frame Support Bar release lever

3) Gently Lower the Reject Frame into place

4) Install the Reject Cassette.

Reject Frame Support Bar release lever
