5-31

Touchscreen Replacement

f The Touchscreen & Display are integrated and must be replaced at the same time.

f DO NOT attempt to separate the Display and Touchscreen

Touchscreen Calibration

No calibration or sensitivity settings are required nor possible.

Touchscreen/Display Assembly

+24 VDC Input

Touchscreen

Backup Flashcard
