Tidel TR303 - Coin Collection Tray Present; Coin Collection Tray Rack; Coin Dispensers (Hoppers); Hardware Support PCB Connections

6-2
6
J18 Coin Collection Tray Present
J19 Coin Collection Tray Rack
J13 Coin Handler Top Cover
J15 Coin Handler/Host Data - RJ-45 cable that comes from the Data Port Coupler
at the top/rear of the Tidel TR250 Coin Handler.
If intergrated with a 3rd party Note Handler:
This cable connects to the coupler labeled “D” at the top/rear of the
Coin Handler.
From the Note Handler coupler “D”, the cable is routed to the Control
Computer port COM5.
J4 Coin Dispensers (Hoppers) - This harness contains a power/comm cable for
each Hopper on the Bulk Coin Dispenser.
J8 Incoming VDC Power - Incoming VDC from the Power Supply.
J7 Vault Door Solenoid - Provides +24 VDC to the solenoid that prevents the
Remote Module Vault Door from being unlocked.
J10 Vault Door Solenoid/Door Position Sensor - The Door Position sensor and
Solenoid Position sensor are wired in series.
Both sensors must be open/closed at the same time for in order to function.
VDC Test Points
TP1 - +5 VDC
TP2 - +12 VDC
TP3 - +24 VDC
TP4 - +24 VDC
Hardware Support PCB Connections
