Tidel TR303 - Feed Module Jam Areas; Note Feeder

To Next Page

To Previous Page

11-26

Feed Module Jam Areas

B9 Door Open

View

Note Feeder - B9 Door

1) Pull the B9 door down

2) Rotate the B6 Knob

INSPECT ALL AREAS FOR JAMS/OBSTRUCTIONS

Feed Module

Knob B6

B9 Door
