Tidel TR303 - Reject Area

To Next Page

To Previous Page

14-47

Reject Cassette Area

#60 Reject Cassette Sensors (2)

#59 - Vacuum, then wipe the entire

Reject Cassette area

(B) Reject Upper Transport

1) Lift the Reject Frame Release Lever and raise the frame fully.

Lift point

See next page for

Reject Transport Area

cleaning

Reject Frame

release lever

(A) Reject Cassette area
