Tidel TR303 - Page 450

To Next Page

To Previous Page

14-48

Reject Upper Transport

#61 - Vacuum, then wipe all Upper

Transport area surfaces

#62 - Upper Belts

#63 - Upper Belts

#65 - Lower Belts

#64 - Back Belts

(B) Reject Upper Transport

#66 - Vacuum, then wipe all

Upper Transport area sufaces

#67 - Transport Door Sensor

#68 Rubber Rollers
