Tidel TR303 - Printer Paper Cutter - Preventive Maintenance

To Next Page

To Previous Page

12-3

Clean with vacuum and

compressed air

Printer Paper Cutter - Preventive Maintenance

Should be vacuumed or blown out with compressed air routinely.

KFI Printer

Thermal paper

Paper width - 79.5 mm (3.13 inches)

Roll diameter - 80 mm or less (3.15 inches)

Thickness - 65 micron (0.065 mm)

Thermal coating on outside of roll

Paper part numbers:

644-0088-003S - Qty = 16 rolls

644-0088-004S - Qty = 8 rolls

Printer Paper Specifications
