13-8
13
Dispenser
The same Dispenser is used for pennies, nickels and dimes,
The Dispenser for quarters is specific to quarters.
Dispenser Magazines should be loaded with MACHINE ROLLED COINS ONLY !
Hand rolled coins can cause jams or dispensing issues.
A +12 VDC motor rotates a cradle at the bottom/front of the Dispenser.
When rolls of coins are dispensed into the receiving tray, they are detected by a sensor located at the
bottom/front of the Dispenser.
The Receiving Tray capacity is limited.
When multiple rolls are requested, dispensing may be interrupted so receiving trays can be cleared,
prior to completing the dispense request.
Receiving Tray capacities:
.01 = 5 rolls .05 = 5 rolls
.10 = 6 rolls .25 = 4 rolls
The Dispenser PCB is equipped with an indicator LED.
A GREEN flashing LED indicates established connection with the Host Controller and no errors.
A RED flashing LED indicates non-communication with the Host Controller or an error condition.
Error conditions can be checked in the Diagnostics menu.
It is recommended that a RESET be performed 1st, followed by a (1 minute minimum) power reset, then
check the statistics.
Log In > (enter Executive code) > More > Maintenance > Diagnostics > Rolled Coin
Dispenser
a) Select “Reset”.
b) Disconnect VAC power (1 minute minimum).
c) Check “Statistics” for existing errors.
