Tidel TR303 - Coin Hoppers - General Information

7-2
7
The Coin Handler vault can contain up to (8) Coin Hoppers.
Hoppers dispense into either a “Coin Collection Tray” or an “Overflow Bin”.
The Coin Collection Tray is typically used when dispensing coins for Till (Shift) Starts or when
additional coins are required.
Coins can be dumped into the Coin Collection Tray (Dump/Coins Out), but may require multiple
removal/unloading in order to dump all coins from the selected Hopper.
Coin Hoppers - General Information
The Overflow Bin is typically used when emptying (dumping) Hoppers for auditing or service.
To dispense coins to the Overflow Bin, the Coin Collection Tray must be removed and the Coin
Collection Tray Rack must be FULLY extended outward.
Coin Handler Vault open
Overflow Bin
Hoppers
Coin Collection Tray Rack
Press Rack Release Lever
DOWN to push rack back
into cabinet
Coin Collection Tray
