Feed Module - Area References
B8 set screw
Lever B8
! DO NOT USE ALCOHOL OR SOLVENTS TO PERFORM CLEANING !
1) Insure the B8 set screw is backed fully away from the B8 lever.
2) Lift lever B8 to fully raise the the Feed Module.
3) Raise the Feed Module until the “shock prop” engages the shock.
Feed Module
Knob B6
B9 Door
B4 Door
Upper Transport
Area
