13-9
13
Dispenser Removal
Slide Release Levers
1) Extend the Dispenser fully from
the cabinet
2) Hold the LEFT side release lever
DOWN.
3) Hold the RIGHT side lever UP.
4) Pull the Dispenser outward from
the slides while holding the
release levers.
Dispenser Installation
1) Extend ONE of the slide rails approximately 6-8”
from the cabinet
2) Engage the Dispenser rail into the slide rail slots
3) Gently insert the Dispenser back into the
cabinet, engaging the 2nd rail set.
4) Push the Dispenser fully into the cabinetoutward
from the slides while holding the release levers.
Insert the Dispenser Rail into the extended
Slide Rail slots and gently push the
dispenser into the cabinet, engaging the
2nd rail
