Tidel TR303 - Adding Users to a User Group

To Next Page

To Previous Page

2-40

Adding Users to a User Group

After adding Users, User must be assigned to a Group, which determines which Departments/

Registers can be accessed.

To add a USER:

Add User

Delete User

Modify User

Add User To Group

Casino Cashier 1

Casino Cashier 2

Casino Manager

Food Cashier 1

Food Cashier 2

Food Manager

Hotel Cashier 1

Hotel Cashier 2

Hotel Manager

Select the desired user

Select the desired User Group

Use these arrows to add/remove

the selected User

DeleteEditNew

Casino Cashiers

Common Cashiers

Executive

Food Cashiers

Hotel Cashiers

Managers
