Tidel TR303 - Feed Module

To Next Page

To Previous Page

14-32

Feed Module

B9 Door Open

View

#16 - Rotate Belts to clean

#15 - Upper Acrylic Lens

#20 - Mid Level Acrylic Lens Bar

(inward facing & under bracket)

#21 - Lower Acrylic Lens Bar

#17 - B9 Door Sensors

#18 - Hidden Sensor

(A) Note Feeder - B9 Door

#14 - Pull B9 Door down (open) and Vacuum entire B9 door interior

#19 - Feed Path Sensors (2)
