14-33

Feed Module

#22 - Vacuum, then wipe the entire Transport interior

#24 - Metal Rollers (16 TOTAL)

#25 - Rubber Rollers (8 TOTAL)

#24 - Metal Rollers (16 TOTAL)

#26 - Rotate Lower belts with

B6 knob to clean

Note Feeder Module

Raised View

(B) Note Feeder - Upper Transport, Belts/Rollers

#23 - Rotate upper belts by hand to clean
