14-34

Feed Module

#27 - Upper Acrylic Lens Bar

#28 - Hidden Sensor

#29 - Transport Sensors

#30 - Feed Module Position Sensor

(D) Note Feeder - B4 Door

#32 - Metal Rollers

#33 - Rubber Rollers

#31 - Push down the B4 Door and Vacuum/Wipe the entire Feed Path area
