Tidel TR303 - Front Transport

To Next Page

To Previous Page

14-37

Front Transport

(A) Front Transport - B24 Door ~ Roller Cleaning

B24 Transport Door

#39 - Metal Rollers (6)

#40 - Rubber Rollers (8)

#38 - Lift the B24 Transport Door and vacuum, then wipe the entire Transort Path area
