14-38

14

Front Transport

(B) Front Transport - B24 Door ~ Belt and Sensor Cleaning

B24 Transport Door

#41 - Upper Lenses

#43 - Rotate Belts by

hand to clean

#44 - Rotate B6

knob to clean rear

belts

#42 - Transport

Sensors

#45 - Clean all

plastic contact

areas.

Front turn (inside)

Floor plates
