14-46

Reject Cassette Sensors

(A) Reject Cassette area

1) Remove the Reject Cassette.

Reject Frame

release lever

Reject Cassette

release lever

Reject Frame

Support Bar release lever

Reject Frame

Support Bar

Lift point
