7-5
7
SN: TF01000
Tidel TR250 Status
1.1.0.0
Hopper 5 Hopper 6Hopper 1 Hopper 2 Hopper 3 Hopper 4
OK
OK OK
OK
OK OK
Coin Recycler
Error Code: NONE
OK
OK OK
System Status
Note Recycler Coin Recycler
Accounting period (06/29/17) Out $525.00
Device Monitor Maintenance Software DataBase Accounting
Backup
Printer
Go Back
System
Coins
Notes
Status
Status Screen Indications
Selecting “STATUS” while the Main Screen is displayed (no User logged in), will present a current
conditions screen (no corrective action can be performed).
Selecting “STATUS” after Log In will allow access to menus which can perform corrective
functions (if the User’s Permission Group allows).
Yellow
Indication
Red
Indication
Typically indicates non-fatal problems that require attention - low cassette
counts, preventive maintenance needs, etc...
Typically indicates a hardware fault or problems that render equipment
inoperable
Select COIN RECYCLER to access function menus
2
1
Select STATUS
To Next Page
