7-13

7

ORG = +24

YLW = +12

WHT = +5

RED = +5

J13

Coin Sorter

Cover Sensor

J7

Coin Handler Vault

Door Solenoid

VDC Test Points

J4

Coin Hopper

Power/Data

Wiring Harness

PRPL = +24

J18

Coin Receiving

Tray Sensor

J19

Coin Tray

Rack Sensors

J10

Coin Hopper

Door Sensors

J15

Computer

Comm

Hardware Support PCB
