Tidel TR303 - Page 41

2
2-3
1
2
3
4
5
6
7
8
11
9
1) Coin Sorter Loading Tray
2) Register Drawer / NFC Scanner
3) Operation Monitor / Touchscreen
4) Finger Print Reader
5) i-Key Reader
6) Note Collection Door
7) Printer Receipt Ejection Slot
8) Foreign Article Reject Tray
9) Bill Recycler Vault Door Access Cover
10) Courier Tray/Drop Slot
11) Coin Sorter Top Cover
12) Bulk Coin Dispenser Vault Access Cover
13) Coin Collection Tray
12
13
10
Component Location - Front View
TR250 Note Handler with TR253 Coin Handler
