Tidel TR303 - Page 421

To Next Page

To Previous Page

14-19

Coin Sorter Cleaning

b) Prop the hood with the Kickstand

a) Raise the Hood

d) Unscrew the Coin Drive Disk Capc) Release the Retainer Band

Carefully remove the Coin Drive Disk
