2-5

TR253 Coin Handler Components

1) Coin Loading Tray

2) Combination Lock

3) Coin Vault Door Handle

4) Coin Collection Tray

5) Coin Collection Tray Rack

6) Overflow Bin

7) Coin Hoppers

3 4
