The following list describes the components of the notation:
◦ rack—Chassis number of the rack.
◦ slot—Physical slot number of the line card.
◦ module—Module number or subslot (for a SPA). A physical layer interface module (PLIM) is
always 0.
◦ port—Physical port number of the interface.
◦ T3num—T3 controller number.
◦ T1num—T1 controller number.
Task ID
OperationsTask ID
readsonet-sdh
Examples
The following example shows sample output from the show controllers t1 lnm command with the all keyword
for a single T1 channel:
RP/0/RSP0/CPU0:router# show controllers t1 0/1/1/0/1/1 lnm all
Thu May 13 10:28:26.474 PDT
Controller T1 0/1/1/0/1/1
Syslog Monitoring type State Thresholds (lcv/pcv/duration)
--------------------------------------------------------------------
enabled minor-warning stable Set( 15/ 15/ 4) Clear( 15/ 15/ 4)
major-warning stable Set( 154/ 145/ 4) Clear( 154/ 145/ 4)
Monitoring type Minor-Warn Major-Warn
--------------- ------------ ------------
Create 1 1
Update 0 0
Delete 0 0
Clear 0 0
Noise Crossed 1 1
Noise Cleared 1 1
Last Five Events
--------------------------------------------------------------------
MINWARNCROSS: Noise crossed minor-warn threshold at Thu May 13 09:54:10 2010
MAJWARNCROSS: Noise crossed major-warn threshold at Thu May 13 09:54:11 2010
MAJWARNCLEAR: Noise cleared major-warn threshold at Thu May 13 10:27:25 2010
MINWARNCLEAR: Noise cleared minor-warn threshold at Thu May 13 10:28:14 2010
The following example shows sample output from the show controllers t1 lnm command with the
configuration keyword for a single T1 channel:
This is also the default output that is displayed if you run the show controllers lnm command without
specifying any keyword options.
Note
RP/0/RSP0/CPU0:router# show controllers t1 0/1/1/0/1/1 lnm configuration
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
1043
T3, E3, T1, E1 Controller Commands on the Cisco ASR 9000 Series Router
show controllers lnm
