The following is sample output from the show controllers sonet command with the framers option:
RP/0/RSP0/CPU0:router# show controllers sonet 0/1/2/1 framers
Common Regs
reg[0] Master Reset and Identity 0x01
reg[1] Master Cfg 0000
reg[3] Master Clock Monitors 0x37
reg[100] Master Intr Status 1 0000
reg[101] Master Intr Status Ch 0-7 0000
reg[102] Master Intr Status Ch 8-15 0000
reg[1000] Master Clock Source Cfg 0000
reg[1001] Master DCC Interface Cfg 1 0x0f
reg[1002] Master DCC Interface Cfg 2 0000
reg[1004] APS Cfg and Status 0000
reg[1005] APS FIFO Cfg and Status 0x0f
reg[1006] APS Intr Status 1 0000
reg[1007] APS Intr Status 2 0000
reg[1008] APS Reset Ctrl 0000
reg[1010] TUL3 Interface Cfg 0x80
reg[1011] TUL3 Intr Status/Enable 1 0000
reg[1012] TUL3 Intr Status/Enable 2 0000
reg[1013] TUL3 ATM Level 3 FIFO Cfg 0x03
reg[1014] TUL3 ATM Level 3 Signal Label 0x01
reg[1015] TUL3 POS Level 3 FIFO Low Water Mark 0x15
reg[1016] TUL3 POS Level 3 FIFO High Water Mark 0x17
reg[1017] TUL3 POS Level 3 Signal Label 0000
reg[1018] TUL3 burst 0x0f
--More--
The following is sample output from the show controllers sonet command with the internal-state keyword:
RP/0/RSP0/CPU0:router# show controllers sonet 0/1/2/1 internal-state
Interface(layer) admin_up if_state
--------------------- -------- --------
SONET0/1/2/1 up up
(SONET Section) up up
(SONET Line) up up
(SONET Path) up up
SonetPath0/1/2/1 up up
POS0/1/2/1 up up
Table 56: show controllers sonet Field Descriptions
DescriptionField
Slot number of the POS interface.Interface (layer)
3
1. section terminating equipment
4
2. line terminating equipment
5
3. path terminating equipment
6
4. loss of frame
7
5. loss of synchronization
8
6. alarm indication signal
9
7. bit interleaved parity
10
8. new data flag
11
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
912
SONET Controller Commands on the Cisco ASR 9000 Series Router
show controllers sonet
