6-6

LEFT SIDE Power Supply

+24 VDC

RED +24 VDCWHT +24 VDC

BLK 110 VACWHT NEUTRAL

AC Voltage In

+24 VDC

Adjustment Potentiometer

GRN GND

Spade connector
