6-7

RIGHT SIDE Power Supply

+5 and +12 VDC

RED +5 VDC BRN +12 VDCWHT +5 VDC

BLK 110 VAC

GRN GND

Spade connector

WHT NEUTRAL

AC Voltage In

+5 VDC Adjustment

Potentiometer (R354)
