14-21

Coin Sorter Cleaning

>>> <<<

>> <<

Coin Exit Sensors

are located under the

Coin Sorting Plate

Coin Exit Sensors

located under the

Coin Sorting Plate

#7 - Clean Sensor Lenses with a cotton swab

>> <<
