14-42

14

#48 Red Rollers #49 Vacuum brushes

Bill Validator

#51 Rubber Rollers

#50 Belts

#51 Rubber Rollers

#50 Belts

#44 Belts

#51 Rubber Rollers

(B) Bill Validator ~ Rollers and Belts
