Functional Verification
Door Operations (continued)
Coin Handler Vault Door
1) Turn the Cash Handler Vault Door “T” Handle(s) to the locked position.
2) Turn the Combination Lock housing Counter-Clockwise (locked).
a) Insure the housing cannot be rotated Clockwise (unlocked).
b) Insure the Vault Door Handle(s) cannot be turned to the unlocked position.
The displayed Sensor Map should indicate the DOOR Sensor is UNLOCKED
3) Block the DOOR Sensor, located in the top/outside corner of the Coin Handler Vault Door.
The displayed Sensor map should indicate the DOOR Sensor is CLOSED.
4) While continuing to block the DOOR Sensor, activate the Solenoid by selecting the Coin
Handler Vault from the Sensor Map.
a) The Solenoid should activate.
b) The displayed Sensor Map should indicate the DOOR Sensor is UNLOCKED.
c) The Door Handle can be turned to the unlocked position.
5) Return the “T” Handle and Combination Lock to the locked position.
6) Enter the combination.
a) 2 beeps indicate correct entry.
b) Rotate the Combination Lock housing clockwise (unlocked)
c) Turn the Vault Door “T” Handle(s) to the UNLOCKED position.
Coin Handler Top Cover
1) Open the Coin Handler Top Cover.
The displayed Sensor map should indicate the sensor is are OPEN.
2) Close the top cover on the Coin Handler
The displayed Sensor map should indicate the Top Cover Sensor is CLOSED.
Fingerprint Reader
1) Navigate to the Fingerprint Reader Test Menu:
Log In > Done > (1-2-3-4-5-6) > Maintenance Menu > Fingerprint Reader
2) When prompted, place a finger onto the Fingerprint Reader lens.
An image of the fingerprint should be displayed
