Cisco Small Business 200 Series

Port Management
Link Aggregation
Cisco Small Business 200E Series Advanced Smart Switch Command Reference 212
3
Related Commands
Port Priority The port priority of the interface when serving as a LAG
partner. The default priority is for a partner is 128. If the
port is not serving as a LAG partner, the priority is 0.
Port ID The port number assigned to the port as a LAG partner
member.
Admin State Indicates the following values, separated by a vertical bar:
ACT or PAS—The port LACP mode:
• ACT (Actor mode)—The port sends LACPDUs on
the switch at a configurable interval.
• PRT (Partner mode)—The port only responds to
LACPDUs sent from active ports.
AGG or IND—The port mode with respect to link
aggregation:
• AGG (Aggregate mode)—The port can participate
in link aggregation.
• IND (Individual mode)—The port cannot participate
in link aggregation.
LTO or LTS—The time after which an LACPDU is no longer
valid:
• LTO (Long Timeout)—The LAG member is
configured to receive less frequent LACP
transmissions and retains the information longer.
• STO (Short Timeout)—The LAG member is
configured to receive more frequent periodic LACP
transmissions and more aggressively times-out
information it receives.
Command Description
show port-
channel brief
Displays the static capability of all LAG interfaces on the
device and a summary of individual LAG interfaces.
