Cisco Small Business 200 Series

Security
Dot1x
Cisco Small Business 200E Series Advanced Smart Switch Command Reference 358
8
e2 auto auto TRUE Authorized
e3 auto auto TRUE Authorized
e4 auto auto TRUE Authorized
e5 auto auto TRUE Authorized
e6 auto auto TRUE Authorized
e7 auto auto TRUE Authorized
e8 auto auto TRUE Authorized
e9 auto auto TRUE Authorized
e10 auto auto TRUE Authorized
e11 auto auto TRUE Authorized
e12 auto auto TRUE Authorized
e13 auto auto TRUE Authorized
e14 auto auto TRUE Authorized
e15 auto auto TRUE Authorized
e16 auto auto TRUE Authorized
e17 auto auto TRUE Authorized
e18 auto auto TRUE Authorized
e19 auto auto TRUE Authorized
e20 auto auto TRUE Authorized
e21 auto auto TRUE Authorized
e22 auto auto TRUE Authorized
e23 auto auto TRUE Authorized
e24 auto auto TRUE Authorized
g1 auto auto TRUE Authorized
g2 auto auto TRUE Authorized
If you use the optional parameter detail interface, the detailed 802.1X
configuration for the specified port is displayed.
(switch) #show dot1x detail e15
Port........................................... e15
Protocol Version............................... 1
PAE Capabilities............................... Authenticator
Control Mode................................... auto
Interface The interface whose configuration is displayed.
Control Mode The configured control mode for this port. Possible values
are force-unauthorized | force-authorized | auto | authorized |
unauthorized.
Operating
Control Mode
The control mode under which this port is operating.
Possible values are auto, force authorized, and force
unauthorized.
Reauthenticatio
n Enabled
Indicates whether re-authentication is enabled on this port.
Port Status Indicates whether the port is authorized or unauthorized.
Possible values are authorized | unauthorized.
