FRONT PARKING, AND TURN SIGNAL LAMP
HOUSING – LHS
The front parking, and turn signal lamp housing is
part of the headlamp housing. For removal procedure
refer to Headlamp Housing Removal and Installation
procedures.
FRONT PARKING, SIDE MARKER, AND TURN
SIGNAL LAMP HOUSING – INTREPID
The front parking, side marker, and turn signal
lamp housing is part of the headlamp housing. For
removal procedure refer to Headlamp Housing
Removal and Installation procedures.
FRONT SIDE MARKER HOUSING – LHS
REMOVAL
(1) Loosen fascia as necessary to access lamp.
(2) Remove bulb socket from lamp.
(3) Disconnect fasteners attaching side marker
lamp to fascia (Fig. 11).
(4) Remove attaching fasteners.
(5) Remove lamp housing from vehicle.
INSTALLATION
(1) Place lamp in position on fascia.
(2) Install lamp fasteners.
(3) Install bulb socket in lamp.
(4) Connect wire harness connector.
(5) Verify lamp operation.
(6) Attach fascia to vehicle.
Fig. 8 Fog Lamp – Intrepid
1 – FOG LAMP
2 – SCREW
Fig. 9 Fog Lamp – LHS
Fig. 10 Fog Lamp – 300M
1 – SCREWS
2 – FOG LAMP
Fig. 11 Front Side Marker Lamp Housing
1 – FOG LAMP
2 – SIDE MARKER
LH LAMPS 8L - 21
REMOVAL AND INSTALLATION (Continued)
