(5) Press and release the UNLOCK button on one
of the RKE transmitters. Do NOT press any switch
for 10 seconds.
(6) Set radio station presets.
To program the second driver’s position, repeat the
above procedure using memory switch 2. The second
RKE transmitter can be programmed in the fashion.
To recall either of the programmed positions
momentarily press and release either memory selec-
tor switch 1 or 2. If using RKE, just press and
release the UNLOCK button on the proper transmit-
ter for either position 1 or 2.
A recall is possible any time the vehicle transmis-
sion is in PARK. This condition is monitored by the
Body Control Module (BCM).
NOTE: The module will abort a recall if the trans-
mission is moved out of park or if any seat move-
ment is activated whether manually or by memory
recall.
REMOVAL AND INSTALLATION
MEMORY HEATED SEAT/MIRROR MODULE
(MHSMM)
REMOVAL
(1) Open hood, disconnect and isolate the negative
battery cable remote terminal from the remote bat-
tery post.
(2) Remove two module attaching screws (Fig. 3).
(3) Disconnect four module connectors.
(4) Remove module from vehicle.
INSTALLATION
For installation, reverse the above procedures.
MEMORY SELECTOR SWITCH
REMOVAL
(1) Disconnect and isolate the negative battery
cable remote terminal from the remote battery post.
(2) Unscrew the side shield on the seat, either
driver or passenger side (Fig. 4).
(3) From the bottom, disengage the switch and
gently rock through the opening.
INSTALLATION
For installation, reverse the above procedures.
Fig. 3 Memory Heated Seat/Mirror Module Location
1 – MHSMM
2 – RECLINER MOTOR
3 – SEAT HEATER 4–WAY CONNECTOR
4 – SEAT BACK HEATER 2–WAY CONNECTOR
5 – REAR RISER
6 – FRONT RISER
7 – HORIZONTAL MOTOR
Fig. 4 Seat Cushion Side Shield
1 – HEATED SEAT SWITCH
2 – POWER SEAT SWITCH
3 – SEAT CUSHION SIDE SHIELD
4 – MEMORY SELECTOR SWITCH
LH POWER SEAT SYSTEMS 8R - 9
SERVICE PROCEDURES (Continued)
2000 LHS, 300M, CONCORDE AND INTREPID
