8W-90 CONNECTOR/GROUND LOCATIONS
INDEX
page page
DESCRIPTION AND OPERATION
CONNECTOR/GROUND LOCATIONS...........1
INTRODUCTION ..........................1
DESCRIPTION AND OPERATION
INTRODUCTION
This section provides illustrations identifying the
general location of components, grounds, and connec-
tors in the vehicle. A index is provided. Use the wir-
ing diagrams in each section for connector/ground
number identification. Refer to the index for the
proper figure number.
CONNECTOR/GROUND LOCATIONS
For items not shown in this section a N/S is placed
in the Fig. column
Connector
Name/Number
Color Location Fig.
A/C Compressor
Clutch
BK Top of
Compressor
5, 6
A/C Pressure
Transducer
Right Front
Engine
Compartment
1, 2
Ambient
Temperature
Sensor
GY Front Grille
Area
1
Analog Clock NAT At Clock N/S
Ash Receiver
Lamp
BK Lower Center
of Instrument
Panel
9
Automatic
Day/Night Mirror
BK At Mirror N/S
Automatic
Temperature
Control Head
BK Center of I/P 9
Autostick Switch Center
Console
10
Blend Door
Actuator
BK Right Side of
HVAC
N/S
Blower Motor
Power Module
BK Right Side of
HVAC
N/S
Blower Motor
Resistor Block
BK Right Side of
HVAC
N/S
Body Control
Module C1
GY Left Side of I/P 8
Body Control
Module C2
BK Left Side of I/P 8
Connector
Name/Number
Color Location Fig.
Body Control
Module C3
WT Left Side of I/P 8
Body Control
Module C4
BL Left Side of I/P 8
Brake Lamp
Switch
GY Top of Brake
Pedal
N/S
Brake Pressure
Switch
BK At Master
Cylinder
4
C101 BK Left Front of
Engine
5, 6,
7
C102 BK Left Front of
Engine
5, 6,
7
C103 GN Left Side
Instrument
Panel
8, 11
C104 OR Left Side
Instrument
Panel
8, 11
C105 YL Left Side
Instrument
Panel
11
C106 Left Side
Instrument
Panel
11
C107 GY Rear of Engine 7
C108 GY Rear of Engine 7
C109 BK Under Left
Front
Headlamp
3
LH 8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 1
