CHIME/BUZZER WARNING SYSTEMS
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION
CHIME/BUZZER WARNING SYSTEM ..........1
DIAGNOSIS AND TESTING
CHIME CONDITIONS ......................2
EXTERIOR LAMPS LEFT ON ................3
FASTEN SEAT BELTS ......................3
KEY LEFT IN IGNITION.....................3
REMOVAL AND INSTALLATION
BODY CONTROL MODULE REMOVAL .........3
HEADLAMP SWITCH ......................3
SEAT BELT BUCKLE .......................3
KEY-IN SWITCH ..........................3
DESCRIPTION AND OPERATION
CHIME/BUZZER WARNING SYSTEM
WARNING: ON VEHICLES EQUIPPED WITH AN AIR-
BAG, REFER TO GROUP 8M, PASSIVE RESTRAINT
SYSTEMS FOR STEERING WHEEL REMOVAL AND
INSTALLATION.
DESCRIPTION
The Chime/Buzzer Warning System includes the
following:
• Exterior Lamps Left On chime. An audible
chime indicates the exterior lamps were left on.
• Fasten Seat Belts chime. A warning lamp on
the instrument panel, and an audible chime are used
as the fasten seat belt warning/reminder.
• Key left in ignition chime. An audible chime
that indicates the ignition key was left in the igni-
tion.
OPERATION
When using the DRB lllt scan tool, refer to the
proper Body Diagnostic Procedures Manual. Refer to
Group 8W, Wiring Diagrams for circuit information.
LH CHIME/BUZZER WARNING SYSTEMS 8U - 1
